| 3.5"/2.5" Universal drive mounts |
6 included, 14 positions total + 1 Multibracket |
| Dedicated 2.5" drive mounts |
2 included, 4 positions total |
| Expansion slots |
7+2 |
| Front interface |
1x USB 3.1 Gen 2 Type-C, 2x USB 3.0, Audio I/O, Power button, Reset button |
| Total fan mounts |
9x 120/140 mm |
| Front fan |
3x 120/140 mm (2x Dynamic X2 GP-14 included) |
| Top fan |
3x 120/140 mm |
| Rear fan |
1x 120/140 mm (1x Dynamic X2 GP-14 included) |
| Bottom fan |
2x 120/140 mm |
| Dust filters |
Top, front and bottom |
| Fixed velcro straps |
Yes |
| Cable routing grommets |
Yes |
| Captive thumbscrews |
HDD, SSD and PSU brackets |
| Left side panel |
Steel |
| Right side panel |
Steel |
| Compatibility |
| Motherboard compatibility |
E-ATX (max 285 mm)/ ATX / mATX / Mini-ITX |
| Power supply type |
ATX |
| Front radiator |
Up to 360/280 mm |
| Top radiator |
Up to 360/420 mm |
| Rear radiator |
120 mm |
| Bottom radiator |
Up to 240/280 mm |
| PSU max length |
250 mm (with HDD cage installed) |
| GPU max length |
Storage layout: 290 mm - Open layout: 470 mm (445 mm w/ front fan) |
| CPU cooler max height |
185 mm |
| Cable routing space |
30 mm |
| Dimensions |
| Case dimensions (L x W x H) |
542 x 240 x 474 mm |
| Case dimensions w/o feet/protrusions/screws |
541 x 240 x 454 mm |
| Net weight |
Solid: 10.1 kg TG: 10.5 kg |
| Package dimensions (L x W x H) |
634 x 542 x 324 mm |
| Gross weight |
Solid: 12.8 kg TG: 13.2 kg |
| Volume |
58.95 liters |
