| 3.5"/2.5" drive mounts |
1 (included) |
| Dedicated 2.5" drive mounts |
3 (2 included) |
| Expansion slots |
2 |
| Front interface |
1x USB 3.1 Gen 2 Type-C, 2x USB 3.0, Audio I/O, Power button, Reset button |
| Total fan mounts |
6x 120 mm or 3x 140 mm (Top 140 mm fans needs to be max 15 mm thick) |
| Front fan |
2x 120/140 mm (1x Dynamic X2 GP-14 included) |
| Top fan |
2x 120 or 1x 140 slim fan (max 15 mm thick) |
| Rear fan |
1x 120 mm (1x Dynamic X2 GP-12 included) |
| Bottom fan |
1x 120 mm (requires removal of HDD tray) |
| Dust filters |
Top, front and bottom |
| Cable routing space |
15-25 mm |
| Cable routing grommets |
Yes |
| Fixed cable straps |
Yes |
| Tool-less push-to-lock |
Top, front and side panels |
| Captive thumbscrews |
SSD and PSU brackets |
| Left side panel |
Tempered glass |
| Right side panel |
Steel |
| Compatibility |
| Motherboard compatibility |
Mini ITX / Mini-DTX |
| Power supply type |
ATX |
| Front radiator |
120/240, 140/280 mm (316 mm max height, 146 mm max width, 280 recommended in “push” configuration for easier fit) |
| Top radiator |
N/A |
| Rear radiator |
120 mm |
| Bottom radiator |
N/A |
| PSU max length |
165 mm recommended (200 mm without HDD-tray and modular air duct) |
| GPU max length |
331 mm 306 mm with front fan |
| GPU max thickness |
57 mm / 2.8 slot |
| CPU cooler max height |
167 mm |
| Dimensions |
| Case dimensions (L x W x H) |
396 x 205 x 361 mm |
| Case dimensions w/o feet/protrusions/screws |
384 x 205 x 345 mm |
| Net weight |
5.9kg (TG) |
| Package dimensions (L x W x H) |
412 x 277 x 462 mm |
| Gross weight |
7.1kg (TG) |
