| 3.5"/2.5" drive mounts |
1 (included) |
| Dedicated 2.5" drive mounts |
3 (included) |
| Expansion slots |
7 |
| Front interface |
1x USB 3.1 Gen 2 Type-C, 2x USB 3.0, Audio |
| Total fan mounts |
2x 180 mm, 4x 140 mm, or 6x 120 mm (with included brackets) |
| Front fan |
2x 180, 2x 140 mm, or 3x 120 mm (with included brackets) (2x Dynamic GP-18 included in standard versions, 2x Prisma AL-18 included in RGB version) |
| Dust filters |
Front, Bottom |
| Cable routing grommets |
Yes |
| Fixed cable straps |
Yes |
| Tool-less push-to-lock |
Side panels |
| Captive thumbscrews |
HDD and SSD brackets |
| Left side panel |
Steel or Tempered glass (RGB version: Tempered glass only) |
| Right side panel |
Steel or Tempered glass (RGB version: Tempered glass only) |
| Compatibility |
| Motherboard compatibility |
E-ATX (up to 274 mm) / ATX / mATX / Mini-ITX / SSI-CEB |
| Power supply type |
ATX |
| Bottom radiator |
Up to 240x120/280x140 mm |
| Rear fan |
1x 120 mm (not included) |
| Bottom fan |
2x 180 mm (with mATX motherboard), 2x 140 mm, or 3x 120 mm |
| Front radiator |
Up to 360x120/280x140 mm (360 mm front radiators (push / push-pull) supported up to a max length of 403 mm) |
| Rear radiator |
120x120 mm |
| PSU max length |
210 mm |
| GPU max length |
330 mm with front fan mounted |
| Cable routing space |
20 mm |
| CPU cooler max height |
174 mm |
| Dimensions |
| Case dimensions (L x W x H) |
450 x 222 x 467 mm |
| Net weight |
BK TGD/TGL: 8.0 kg, WT TGC: 7.7 kg, BK Solid: 7.4 kg |
| Package dimensions (L x W x H) |
535 x 306 x 574 mm |
| Gross weight |
BK TGD/TGL: 9.7 kg, WT TGC: 9.5 kg, BK Solid: 9.2 kg |
