| 3.5"/2.5" drive mounts |
1 (included) |
| Dedicated 2.5" drive mounts |
2 (included) |
| Expansion slots |
3 |
| Front interface |
1x USB 3.1 Gen 2 Type-C, 2x USB 3.0, Audio |
| Total fan mounts |
1x 180 mm, 4x 140 mm, or 5x 120 mm (with included brackets) |
| Front fan |
1x 180 mm or 2x 140/120 mm (with included bracket) (1x Dynamic GP-18 included in standard versions, 1x Prisma AL-18 included in RGB version) |
| Dust filters |
Front, Bottom |
| Cable routing grommets |
Yes |
| Fixed cable straps |
Yes |
| Tool-less push-to-lock |
Side panels |
| Captive thumbscrews |
HDD and SSD brackets |
| Left side panel |
Steel or Tempered glass (RGB version: Tempered glass only) |
| Right side panel |
Steel or Tempered glass (RGB version: Tempered glass only) |
| Compatibility |
| Motherboard compatibility |
mITX / mDTX |
| Power supply type |
ATX |
| Bottom fan |
2x 140/120 mm (not included) |
| Front radiator |
Up to 240/140 mm |
| Rear fan |
1x 120 mm (not included) |
| Rear radiator |
120 mm |
| Bottom radiator |
Up to 240/280 mm |
| PSU max length |
200 mm |
| GPU max length |
335 mm with front fan mounted |
| Cable routing space |
29 mm |
| CPU cooler max height |
165 mm |
| Dimensions |
| Case dimensions (L x W x H) |
417 x 222 x 374 mm |
| Net weight |
BK TGD/TGL: 6.0 kg, WT TGC: 5.8 kg, BK Solid: 5.5 kg |
| Package dimensions (L x W x H) |
446 x 300 x 538 mm |
| Gross weight |
BK TGD/TGL: 7.8 kg, WT TGC: 7.5 kg, BK Solid: 7.2 kg |
