| 80PLUS certification |
Gold |
| Modular cables |
Fully Modular |
| Fan type |
140 mm LLS bearing Fractal Design Dynamic series fan |
| Maximum operating temperature (full load) |
40°C, 50°C at 80% load |
| Semi-passive operation |
No |
| Capacitors |
Primary side: Japanese 105° main bulk capacitor(s), Secondary side: Taiwanese 105°C electrolytic & solid-state capacitors |
| Life expectancy |
100,000 hours |
| Cable type |
Modular 24-pin cable: Black wires in braided sleeve, Other modular cables: Flat black wires |
| Input voltage |
100-240V AC |
| Input frequency |
50-60 Hz |
| Input current |
10A/5A |
| Protection features |
Over voltage protection, Under voltage protection, Over-power protection, Short circuit protection, Over current protection, Over temperature protection |
| PSU specification compliance |
ATX12V 2.52; EPS12V 2.92 |
| PSU color |
Black |
| Sleep state compliance |
C6/C7 compatible |
| Approvals & certifications |
CE, FCC, KCC, TUV, cTUVus, EAC, RCM, CCC, BSMI, CB, RoHS, WEEE |
| Warranty |
7 years |
| Connectors |
| ATX 24-pin |
1 |
| EPS/ATX12V |
1 |
| PCIe |
4 |
| SATA |
6 |
| Peripheral |
3 |
| DC Output |
| 3.3V |
20A |
| 5V |
20A |
| 3.3V and 5V combined |
110W |
| 12V |
54.1A |
| -12V |
0.3A |
| +5Vsb |
3A |
| Total Power |
650W |
| Cable Configuration (length in mm between connectors) |
| ATX 24-pin |
500 |
| ATX 12V 4+4 pin |
600 |
| EPS12V 8-pin |
N/A |
| PCIe 6+2 pin |
550+150v |
| SATA |
500+150+150 |
| Peripheral |
500+150+150 |
