FRACTAL DESIGN zdroj Ion 750 W GOLD, modular, 80+ Gold
Výkon zdroje (W):750; Formát zdroje:ATX; Konektory:8pin CPU 1x, 8pin CPU 2x, PCIe 6-pin, PCIe 8-pin, SATA 15-pin; Konektory pro základní desku:ATX 20-pin, ATX 24-pin, EPS 8-pin; Modulární kabeláž; Efektivita zdroje:80 Plus Gold; Vlastnosti zdroje:Modulární kabeláž; Podsvícení:Bez podsvícení
Dostupnost:
Není skladem - je u dodavatele na objednání.
Kód:
1208158
Typové označení výrobce :
FD-P-IA2G-750-EU
Ion Gold 750W
The Ion Gold ATX is a high-performance power supply, featuring great electrical performance, quiet operation and a big 140 mm Dynamic series fan. Tailored specifically for anyone looking for a high-quality power supply at a competitive price, the Ion Gold comes packed with capability.
- 80PLUS Gold Efficiency rating for reduced noise and energy consumption
- Premium Japanese 105°C capacitor(s) on the primary side for superior reliability and durability
- Fully modular design for reduced clutter and maximum ease of installation
TECHNICAL SPECIFICATIONS
| 80PLUS certification |
Gold |
| Modular cables |
Fully Modular |
| Fan type |
140 mm LLS bearing Fractal Design Dynamic series fan |
| Maximum operating temperature (full load) |
40°C, 50°C at 80% load |
| Semi-passive operation |
No |
| Capacitors |
Primary side: Japanese 105° main bulk capacitor(s), Secondary side: Taiwanese 105°C electrolytic & solid-state capacitors |
| Life expectancy |
100,000 hours |
| Cable type |
Modular 24-pin cable: Black wires in braided sleeve, Other modular cables: Flat black wires |
| Input voltage |
100-240V AC |
| Input frequency |
50-60 Hz |
| Input current |
10A/5A |
| Protection features |
Over voltage protection, Under voltage protection, Over-power protection, Short circuit protection, Over current protection, Over temperature protection |
| PSU specification compliance |
ATX12V 2.52; EPS12V 2.92 |
| PSU color |
Black |
| Sleep state compliance |
C6/C7 compatible |
| Approvals & certifications |
CE, FCC, KCC, TUV, cTUVus, EAC, RCM, CCC, BSMI, CB, RoHS, WEEE |
| Warranty |
7 years |
| Connectors |
| ATX 24-pin |
1 |
| EPS/ATX12V |
2 |
| PCIe |
4 |
| SATA |
8 |
| Peripheral |
3 |
| DC Output |
| 3.3V |
22A |
| 5V |
22A |
| 3.3V and 5V combined |
120W |
| 12V |
62.5A |
| -12V |
0.3A |
| +5Vsb |
3A |
| Total Power |
750W |
| Cable Configuration (length in mm between connectors) |
| ATX 24-pin |
500 |
| ATX 12V 4+4 pin |
600 |
| EPS12V 8-pin |
600 |
| PCIe 6+2 pin |
550+150 |
| SATA |
500+150+150+150 |
| Peripheral |
500+150+150 |
