| Tech Spec |
|
|
Panel
|
|
|
Screen Size
|
110" |
| Panel Technology |
ADS |
| Back Light Type |
Direct |
| Aspect Ratio |
16:09 |
| Native Resolution |
3,840 x 2,160 (4K UHD) |
| Refresh Rate |
120 Hz |
| Brightness (Typ.) |
500 nit |
| Contrast Ratio |
1,200 : 1 |
| Dynamic CR |
1,000,000 : 1 |
| Color gamut |
DCI-P3 88%^ |
| Viewing Angle (H x V) |
178 × 178 |
| Color Depth |
1.07 Billion Colors (8 bits + FRC) |
| Response Time |
8 ms (G to G) |
| Surface Treatment (Haze) |
1% |
| Lifetime |
50,000(Typ.) |
| Operation Hours (Hours / Days) |
16.VII |
| Portrait / Landscape |
No / Yes |
|
Mechanical
|
|
| Specification |
|
|
Bezel Color
|
Black |
| Bezel Width |
17 mm (Even Bezel) |
| Weight (Head) |
80 kg |
| Packed Weight |
110 kg |
| Monitor Dimensions (W × H × D) |
2,474 × 1,408 × 99 mm |
| Carton Dimensions (W × H × D) |
2,680 × 1,730 × 320 mm |
| Handle |
Yes |
| VESA™ Standard Mount Interface |
1,500 × 600 mm |
|
Key Feature (Hardware)
|
|
|
Internal Memory
|
16 GB |
| Wi-Fi |
Built-in Wi-Fi |
| Temperature Sensor |
Yes |
| Auto Brightness Sensor |
Yes |
| Acceleration(Gyro) Sensor |
Yes |
| Local Key Operation |
Yes |
| Power Indicator |
Yes |
|
Key Feature (Software)
|
|
|
webOS ver.
|
webOS 6.0 |
| Local Contents Scheduling |
Yes |
| Group Manager |
Yes |
| USB Plug & Play |
Yes |
| Fail over |
Yes |
| Booting Logo Image |
Yes |
| No Signal Image |
Yes |
| Local Network Sync |
Yes |
| PIP |
Yes |
| PBP |
Yes (4) |
| Screen Share |
Yes |
| Video Tag |
Yes (4) |
| Play via URL |
Yes |
| Tile Mode Setting |
Yes (Max. 15x15) |
| Setting Data Cloning |
Yes |
| SNMP |
Yes |
| ISM Method |
Yes |
| Auto Set ID |
Yes |
| Status Mailing |
Yes |
| Control Manager |
Yes |
| Cisco Certi. |
Yes |
| Crestron Inside |
Yes |
| Smart Energy Saving |
Yes |
| PM mode |
Yes |
| Wake on LAN |
Yes |
| Network Ready |
Yes |
| Beacon |
Yes |
| HDMI-CEC |
Yes |
| SI Server Setting |
Yes |
| webRTC |
Yes |
| Pro:Idiom |
Yes |
|
Environment Conditions
|
|
|
Operation Temperature
|
0°C to 40°C |
| Operation Humidity |
10 % to 80 % |
|
Power
|
|
|
Power Supply
|
AC 100-240 V~, 50/60 Hz |
| Power Type |
Built-In Power |
|
Power Consumption
|
|
|
Typ./Max.
|
440 W / 570 W |
| Smart Energy Saving (70%) |
308 W |
| DPM |
0.5 W |
| Power off |
0.5 W |
| BTU (British Thermal Unit) |
1,501 BTU/Hr (Typ.), 1,945 BTU/Hr (Max) |
|
OPS Compatibility
|
|
|
OPS Type Compatible
|
No |
| OPS Power Built In |
No |
|
Software Compatibility
|
|
| |
SuperSign CMS, SuperSign Control+, SuperSign WB, SuperSign Cloud, Mobile CMS, LG ConnectedCare |
|
Connectivity
|
|
|
Input
|
HDMI (3 (HDMI1/2 : HDCP 2.2/1.4, HDMI3)), DP (HDCP 2.2/1.3), DVI-D (HDCP 1.4), Audio In, RS-232C (4 Pin Phone-jack), RJ45 (LAN), IR In, USB 2.0 Type A |
| Output |
HDMI Out, Audio Out, RS-232C Out (4 Pin Phone-jack), Daisy Chain (Input HDMI, DP, DVI / Output HDMI) |
|
Sound
|
|
|
Speaker
|
Yes (10W X 2) |
|
Language
|
|
| |
English, French, German, Spanish, Italian, Korean , Chinese(Simplified), Chinese(Original), Portugues(Brazil), Swedish, Finnish, Norwegian, Danish, Russian, Japanese, Portugues(Europe), Dutch, Czech, Greek, Türkiye, Arabic, Polski |
|
Certification
|
|
|
Safety
|
CB / NRTL |
| EMC |
FCC Class "A" / CE / KC |
| ErP |
Yes (NewErP) |
|
Accessory
|
|
|
Basic
|
Remote Controller(include battery 2ea), Power Cord, QSG, IR/Light sensor receiver, Regulation Book, Phone to RS232C Gender |
| Optional |
No |
