| Tech Spec |
|
|
Panel
|
|
|
Screen Size
|
43" |
| Panel Technology |
IPS |
| Back Light Type |
Edge |
| Aspect Ratio |
16:09 |
| Native Resolution |
3,840 x 2,160 (4K UHD) |
| Refresh Rate |
60 Hz |
| Brightness (Typ.) |
700 nit |
| Contrast Ratio |
1,000 : 1 |
| Dynamic CR |
1,000,000 : 1 |
| Color gamut |
BT709 95% |
| Viewing Angle (H x V) |
178 × 178 |
| Color Depth |
1.07 Billion Colors (8 bit (D)) |
| Response Time |
8ms (G to G) |
| Surface Treatment (Haze) |
25% |
| Life Time (Min.) |
50,000 Hrs |
| Operation Hours (Hours / Days) |
24.VII |
| Portrait / Landscape |
Yes / Yes |
|
Mechanical
|
|
| Specification |
|
|
Bezel Color
|
Black |
| Bezel Width |
8.9 mm (T/R/L), 12.9 mm (B) |
| Weight (Head) |
11.1 kg |
| Packed Weight |
12.8 kg |
| Monitor Dimensions (W × H × D) |
963 x 556.2 x 29.7mm (without IR) |
| Carton Dimensions (W × H × D) |
1,055 x 660 x 142 mm |
| Handle |
No |
| VESA™ Standard Mount Interface |
200 × 200 mm |
|
Key Feature
|
|
|
|
Internal Memory 16 GB, Built-in Wi-Fi, Sensor (Temperature Sensor, Auto Brightness Sensor (External IR), Acceleration (Gyro) Sensor), Local Key Operation, Built-in Speaker (10W X 2), webOS 6.0, Local Contents Scheduling, Group Manager, USB Plug & Play, Fail Over, Image (Booting Logo Image, No Signal Image), Sync (RS-232C Sync, Local Network Sync), PIP, PBP (4), Screen Share, Video Tag (4), Play via URL, Rotation (Screen Rotation, External Input Rotation), Gapless Playback, Tile Mode Setting (Max. 15 × 15), Setting Data Cloning, SNMP, ISM Method, Auto Set ID, Status Mailing, Control Manager, 3rd Party Compatibility (Cisco Certification (TBD), Crestron Connected), Smart Energy Saving, PM Mode, Wake on LAN, Network Ready, Beacon, HDMI-CEC, SI Server Setting, webRTC, Pro:Idiom |
|
Environment Conditions
|
|
|
Operation Temperature
|
0 °C to 40 °C |
| Operation Humidity |
10 % to 80 % |
|
Power
|
|
|
Power Supply
|
AC 100-240 V ~, 50/60 Hz |
| Power Type |
Built-In Power |
|
Power Consumption
|
|
|
Typ./Max.
|
80 W / 120 W |
| Smart Energy Saving (70%) |
56 W |
| DPM |
0.5 W |
| Power off |
0.5 W |
|
Standard (Certification)
|
|
|
|
BS476 Part7 : Class 1 (case top / back cover) |
| |
EN13501-1 : Class A1 (case top) / Class A2 (back cover) |
|
Certification
|
|
|
Safety
|
CB / NRTL |
| EMC |
FCC Class “B" / CE / KC |
| ePEAT (US Only) |
Yes |
| ErP / Energy Star |
Yes (NewErP) / Yes |
| ISTA6 |
Yes (~'23.9, US Suffix Only) |
| Carbon Trust |
Yes (CO2 Measured (TBD)) |
|
OPS Compatibility
|
|
|
OPS Type Compatible
|
No |
| OPS Power Built In |
No |
|
Software Compatibility
|
|
|
|
SuperSign CMS, SuperSign Control / Control+, SuperSign WB, SuperSign Cloud, Mobile CMS, LG ConnectedCare |
|
Connectivity
|
|
|
Input
|
HDMI In (2, 3,840 × 2,160 @ 60 Hz, HDCP 2.2/1.4), DP In (3840 × 2,160 @ 60 Hz, HDCP 2.2/1.3), RS-232C In (4 Pin Phone-jack), RJ45 (LAN) In, IR In, USB In 2.0 ((Type A) (Type C, without PD function)) |
| Output |
DP Out (3,840 × 2,160 @ 60 Hz, Input (HDMI 1/2/DP/USB-C)), Audio Out, RS-232C Out (4 Pin Phone-jack), Daisy Chain (Input HDMI, DP, USB C / Output DP) |
|
Language
|
|
| |
English, French, German, Spanish, Italian, Korean , Chinese(Simplified), Chinese(Original), Portugues(Brazil), Swedish, Finnish, Norwegian, Danish, Russian, Japanese, Portugues(Europe), Dutch, Czech, Greek, Türkiye, Arabic |
|
Accessory
|
|
|
Basic
|
Remote Controller, Power Cord, QSG, Regulation Book, Phone to RS-232C Gender, USB-C Cable, Cable Holder (2 ea), AC Cord Holder (1 ea) |
| Optional |
Slim Wall Mount (WB21LM A/B), Normal Wall Mount (LSW240 A/B) Wall Mount Adapter (AM-B220S) |
|
Special Feature
|
|
|
Tilt (Facedown)
|
Yes (Max 30o degree, 40oC temperature) |
| IP Rating |
IP5X |
| Conformal Coating (Power Board) |
Yes |
