| HARDWARE FEATURES |
|
| Interface |
• 6× 10/100 Mbps RJ45 Ports (4× 10/100 Mbps 802.3af/at PoE Ports)
• AUTO Negotiation
• AUTO MDI/MDIX |
| Network Media |
• 10BASE-T: UTP category 3, 4, 5 cable (maximum 100m); EIA/TIA-568 100? STP (maximum 100m)
• 100BASE-TX: UTP category 5, 5e cable (maximum 100m); EIA/TIA-568 100? STP (maximum 100m) |
| Fan Quantity |
Fanless |
| Installation |
• Desktop
• Wall Mounting |
| Power Supply |
External Power Adapter (Output: 53.5VDC / 0.81A) |
| PoE Ports (RJ45) |
• Standard: 802.3 af/at compliant
• PoE Ports: Ports 1–4, up to 15.4 W PoE output per port
• Power Supply: 41 W |
| LED Indicator |
• Power
• Link/Act
• PoE Status
• PoE MAX |
| Dimensions ( W x D x H ) |
6.2×4.0×1.0 in (158×101×25 mm) |
| Max Power Consumption |
• 2.53 W (220 V/50 Hz no PD connected)
• 47.76 W (220 V/50 Hz with 41 W PD connected) |
| Max Heat Dissipation |
• 8.61 BTU/h (220 V/50 Hz no PD connected)
• 162.38 BTU/h (220 V/50 Hz with 41 W PD connected) |
| PERFORMANCE |
|
| Switching Capacity |
1.2 Gbps |
| Packet Forwarding Rate |
0.8928 Mpps |
| MAC Address Table |
2K |
| Jumbo Frame |
2 KB |
| SOFTWARE FEATURES |
|
| Advanced Features |
• Extend Mode Button (Ports 1–4, Up to 250 m PoE power supply and data transmission)
• PoE Auto Recovery Button (Ports 1-4)
• Compatible With IEEE 802.3af/at Compliant PDs
• Mac Address Auto-Learning and Auto-Aging
• IEEE 802.3x Flow Control
• Green Technology |
| Transfer Method |
Store and Forward |
| OTHERS |
|
| Certification |
CE, FCC, RoHS |
| Package Contents |
• LS106LP
• Power Adapter
• Installation Guide |
| Environment |
• Operating Temperature: 0–40 °C (32–104 °F)
• Storage Temperature: -40–70 °C (-40–158 °F)
• Operating Humidity: 10–90% RH non-condensing
• Storage Humidity: 5–90% RH non-condensing |
