| HARDWARE FEATURES |
|
| Interface |
10/100Mbps Ethernet Port*2
USB 2.0 Port*1
Micro USB Port*1 |
| Power Supply |
802.3af/at PoE or Micro USB(DC 5V/Minimum 1A) |
| Dimensions |
3.9×3.9×1.0in. (100×98×25mm) |
| FEATURES |
|
| Wireless Fuction |
L3 Management
Multi-SSID
Load Balance
Band Steering
Airtime Fariness
Beamforming
Rate Limit
Wireless Schedule
QoS |
| Wireless Security |
Captive Portal Authentication
Access Control
Wireless Mac Address Filtering
Wireless Isolation Between Clients
SSID to VLAN Mapping
Rogue AP Detection |
| AP Management |
Automatic Discovery
Unified Configuration
Reboot Schedule
Batch Firmware Upgrade
LED ON/OFF
Management Scale - up to 50 AP´s |
| Authentication |
Captive Portal |
| MANAGEMENT |
|
| Omada App |
Yes |
| Centralized Management |
• Up to 100 Omada access points, 20 JetStream switches, and 10 Omada routers
• Up to 1,000 Clients
Note: Please refer to www.tp-link.com/en/business-networking/all-omada/ to find all the device models supported by OC200 |
| Cloud Access |
Yes |
| L3 Management |
Yes |
| Multi-site Management |
Yes |
| Management Features |
• Automatic Device Discovery
• Batch Configuration
• Batch Firmware Upgrading
• Intelligent Network Monitoring
• Abnormal Event Warnings
• Unified Configuration
• Reboot Schedule
• Captive Portal Configuration |
| OTHERS |
|
| Certification |
CE, FCC, RoHS |
| Package Contents |
Omada Cloud Controller
OC200
Quick Installation Guide
Ethernet Cable |
| System Requirements |
Microsoft Windows10, 8, 7,Vista™, XP or MAC OS, NetWare, UNIX or Linux |
| Environment |
Operating Temperature: 0°C~40°C (32°F~104°F)
Storage Temperature: -40°C~70°C (-40°F~158°F)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing |
