| HARDWARE FEATURES |
| Standards and Protocols | IEEE802.3i, IEEE802.3u, IEEE802.3ab, IEEE802.3af, IEEE802.3at, IEEE802.3bt |
| Network Media | 10BASE-T: UTP category 3, 4, 5 cable (maximum 100 m)
EIA/TIA-568 100? STP (maximum 100 m)
100BASE-TX: UTP category 5, 5e cable (maximum 100 m)
EIA/TIA-568 100? STP (maximum 100 m)
1000BASE-T: UTP category 5, 5e, 6 cable(maximum 100 m)
|
| Ports | 1× 10 Gbps/5 Gbps/2.5 Gbps/1 Gbps/100 Mbps/10 Mbps RJ45 data-in port
1× 10 Gbps/5 Gbps/2.5 Gbps/1 Gbps/100 Mbps/10 Mbps RJ45 power+data-out port (Max. 90 W)
1× AC socket |
| Power Consumption | • Input: 100-240 V, 50/60 Hz, 1.6A
• Output: Auto-determine the necessary power requirements (max. 90 W) |
| Basic Function | • Auto-Sensing Algorithm enables providing power with 802.3af/at PD
• Auto-determine the necessary power requirements
• Wall-mounting and desktop installation supported
• Plug-and-Play |
| LED Indicator | Power / PoE |
| Dimensions ( W x D x H ) | 6.1×2.8×1.7 in (155×70×42 mm) |
| OTHERS |
| Certification | FCC, CE, RoHS |
| Package Contents | • POE380S
• Installation Guide
• Power Cord |
| Environment | • Operating Temperature: 0°C to 45°C (32°F to 113°F)
• Storage Temperature: -40°C to 70°C (-40°F to 158°F)
• Operating Humidity: 10% to 90%RH non-condensing
• Storage Humidity: 5% to 90%RH non-condensing |
