| WIRELESS |
|
| Working Modes |
Range Extender, Access Point |
| HARDWARE FEATURES |
|
| Ports |
1 Gigabit Ethernet Port |
| Button |
WPS Button, Reset Button |
| Input Power |
100-240V~50/60Hz |
| Power Consumption |
10W |
| Dimensions ( W x D x H ) |
2.9×1.8×4.9 in. (74.0×46×124.8 mm) |
| Antenna |
2 External Antennas |
| WIRELESS FEATURES |
|
| Wireless Standards |
IEEE 802.11a/n/ac/ax 5GHz, IEEE 802.11b/g/n/ax 2.4GHz |
| Frequency |
2.4GHz and 5GHz |
| Signal Rate |
574 Mbps at 2.4GHz, 1201 Mbps at 5GHz |
| Reception Sensitivity |
5 GHz: 11ax HE80 MCS0: -87dBm, 11ax HE80 MCS11: -56dBm 11a 6Mbps: -93dBm, 11a 54Mbps: -75dBm 11ac HT20 MCS0: -92dBm, 11ac HT20 MCS8: -70dBm 11ac HT40 MCS0: -90dBm, 11ac HT40 MCS9: -66dBm 11ac HT80 MCS0: -87dBm, 11ac HT80 MCS9: -62dBm 2.4 GHz: 11ax HE40 MCS0: -93dBm, 11ax HE40 MCS11: -63dBm 11g 54Mbps: -77dBm, 11n HT20 MCS7: -75dBm 11n HT40 MCS7: -72dBm |
| Transmit Power |
CE: 2.4 GHz ?15dBm, 5 GHz ?21dBm |
| Wireless Functions |
Enable/Disable Wireless Radio, Wireless Statistics |
| Wireless Security |
64/128-bit WEP, WPA/WPA-PSK2 encryptions |
| OTHERS |
|
| Certification |
CE, RoHS |
| Package Contents |
Wi-Fi Range Extender RE605X Quick Installation Guide |
| System Requirements |
Microsoft Windows 98SE, NT, 2000, XP, Vista™ or Windows 7, 8, 8.1, 10, MAC OS, NetWare, UNIX or Linux Internet Explorer 11, Firefox 12.0, Chrome 20.0, Safari 4.0, or other Java-enabled browser |
| Certifications |
FCC, RoHS |
