| CAMERA |
| Image Sensor | 1/2.8'' Progressive Scan CMOS Not Starlight Sensor |
| Lens | Focal Length: 3.83mm
Aperture: F2.4Field of View:107.52° (Diagonal),
88.11°(Horizontal), 46.65°(Vertical) |
| Motion Range | Pan Mechanical Range: 340°
Tilt Mechanical Range: 70° |
| Night Vision | 850 nm IR LED (40 ft ) |
| Interface & Button | 1× RESET Button
1× MicroSD Card Slot (Up to 512 GB) |
| VIDEO & AUDIO |
| Maximum Resolution | 1080p Full HD (1920 × 1080 px) |
| Frame Rate | 15/20/25/30 fps (Default 15 fps, can be set up to 30 fps) |
| Digital Zoom | None |
| Video Compression | H.264 |
| Live View | Yes |
| Image Enhancement | 3D DNR WDR |
| Audio Input & Output | Built-in Microphone and Speaker |
| Audio Communication | Two-Way Audio with Noise Cancellation |
| Siren Volume | 90dB (Level measured at 4-inch/10-cm distance) |
| STORAGE |
| Local Storage | MicroSD Card Slot on Camera (Up to 512 GB)
|
General Information about using MicroSD Cards >
| Cloud Storage | Tapo Care Cloud Storage Services (Subscription required) |
| DETECTION and NOTIFICATIONS |
| AI Detection | Motion Detection
Person Detection
Baby Crying Detection |
| Activity Zones | Yes |
| Output Notification | System Notification
System Notification with Snapshot (Tapo Care Services) |
| NETWORK |
| Network Connectivity | Connect via Wi-Fi or Ethernet cable |
| Wireless Connectivity | IEEE 802.11b/g/n, 2.4 GHz Wi-Fi |
| Ethernet Port | 1× 100 Mbps RJ45 Port on Camera |
| RTSP | Yes |
| SECURITY |
| Security | On-Device Machine Learning
128-bit AES Encryption with SSL/TLS
WPA/WPA2-PSK |
| GENERAL |
| Smart Integration | Google Assistant, Amazon Alexa |
| System Requirements | Tapo App: iOS 9.0 or higher, Andriod 4.4 or higher |
| Mounting Options | Tabletop
Ceiling-Mounted |
| Operating Temperature | 0?~40? |
| Storage Temperature | -40?~70? |
| Operating Humidity | 10%~95%RH |
| Storage Humidity | 5%~90%RH |
| Package Content |
| Package Content | Tapo Pan/Tilt Home Security Wi-Fi Camera
Power Adapter
Quick Start Guide
Mounting Screws
Mounting Plate
Camera Base |
