| CAMERA |
|
| Image Sensor |
1/3” |
| Lens |
Focal Length: 4.0mm±5%
F/NO: 2.0±10% |
| Night Vision |
850nm IR LED Night Vision up to 30ft |
| Pan/Tilt Range |
360° Horizontal
114° Vertical |
| Resolution |
2K 4MP QHD (2560 * 1440 px) |
| NETWORK |
|
| Protocol |
TCP/IP, DHCP, ICMP, DNS, NTP, HTTPS, TCP, UDP |
| Wireless Rate |
11Mbps(802.11b)
54Mbps(802.11g)
72.2Mbps(802.11n) |
| ONVIF |
Supported |
| Cloud |
Supported |
| Security |
128 bit AES encryption with SSL/TLS |
| POWER |
|
| Camera input |
3 Meter Power Cable |
| ACTIVITY NOTIFICATIONS |
|
| Input Trigger |
Motion detection?Person detection?line Crossing detection?Tamper detection?Baby Crying Detection?Vehicle Detection?Pet Detection?Meow Detection?Bark Detection?Glass Detection |
| Output Notification |
Notification,
Snapshot(Tapo care)
Clips(Tapo care) |
| ENVIRONMENT |
|
| Operating Temperature |
0°C~40°C |
| Storage Temperature |
-20°F~60°F |
| Operating Humidity |
10%~90%RH, Non-condensing |
| Storage Humidity |
5%~90%RH, Non-condensing |
| PACKAGE CONTENTS |
|
| Package Contents |
Tapo Pan/Tilt Home Security Wi-Fi Camera
Power Adapter
Quick Start Guide
Mounting Screws
Mounting Plate
Camera Base |
| HARDWARE |
|
| Button |
Reset Button |
| Indicator LED |
System LED |
| Adapter Input |
100-240VAC, 50/60Hz, 0.3A |
| Adapter Output |
9.0V/0.6A |
| Product Dimensions (W x D x H) |
3.4 x 3.3 x 4.6 in. (86.6 x 85 x 117.7 mm) |
| AUDIO |
|
| Audio Communication |
Two-Way Audio |
| Audio Input & Output: |
Built-in microphone and speaker |
| VIDEO |
|
| Frame Rate |
2560×1440@30fps |
| Video Compression |
H.264 |
