| HARDWARE FEATURES |
|
| Plug Type |
UK |
| Standards and Protocols |
HomePlug AV2, HomePlug AV, IEEE 1901,
IEEE 802.3, IEEE 802.3u, IEEE 802.3ab |
| Interface |
Gigabit Ethernet Port |
| Button |
Pair/Reset button |
| Power Consumption |
Maximum: 2.7W (220V/50Hz)
Typical: 2.3W (220V/50Hz)
Standby: 0.5W (220V/50Hz) |
| LED Indicator |
PWR, PLC, ETH |
| Dimensions ( W x D x H ) |
2.6*2.0*1.1 in (65*52*28.5mm) |
| Range |
300 Meters over electrical circuit |
| SOFTWARE FEATURES |
|
| Modulation Technology |
OFDM (PLC) |
| Encryption |
Powerline Security: 128-bit AES |
| OTHERS |
|
| Certification |
CE, RoHS |
| Package Contents |
Powerline Ethernet Adapter
6.5 ft. (2 m) Ethernet cable (RJ45)
Quick Installation Guide |
| System Requirements |
Windows 2000/XP/2003/Vista, Windows 7/8/8.1, Mac, Linux |
| Environment |
Operating Temperature: 0°C~40°C (32°F ~104°F)
Storage Temperature: -40°C~70°C (-40°F ~158°F)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing |
