| HARDWARE FEATURES |
|
| Plug Type |
EU |
| Standards and Protocols |
HomePlug AV2, HomePlug AV, IEEE 1901, IEEE 802.3, IEEE
802.3u, IEEE 802.3ab |
| Interface |
2 * 10/100Mbps Ethernet Ports –TL-WPA4220
2 * 10/100Mbps Ethernet Ports – TL-PA4020P
Power Socket |
| Button |
Pair Button, Wi-Fi Button, Reset Button |
| Power Consumption |
TL-WPA4220 Power Consumption: Maximum: 5.6W, Typical: 5.2W
TL-PA4020P Power Consumption: Maximum: 3.26W, Typical: 2.58W, Standby: 0.83W |
| LED Indicator |
Power, Powerline, Ethernet, Wi-Fi |
| Dimensions ( W x D x H ) |
TL-WPA4220: 2.1 × 1.6 ×3.7 in (54 × 40 × 94 mm)
TL-PA4020P: 2.3 × 1.7 × 3.7 in (58 × 42 × 95mm) |
| Range |
Up to 300 meters/1,000 feet over existing electrical wiring |
| SOFTWARE FEATURES |
|
| Modulation Technology |
OFDM (PLC) |
| Encryption |
Wireless Security: WPA-PSK / WPA2-PSK, WEP Encryptions
Powerline Security: 128-bit AES |
| OTHERS |
|
| Certification |
CE, RoHS |
| Package Contents |
AV600 Powerline Wi-Fi Kit
1 × TL-WPA4220 (Wi-Fi Extender)
1 × TL-PA4020P
2 × Ethernet Cables
1 × Quick Installation Guide |
| System Requirements |
Windows 2000/XP/2003/Vista, Windows 7/8/8.1/10, Mac, Linux |
| Environment |
Operating Temperature: 0°C~40°C (32°F ~104°F)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing |
