| HARDWARE FEATURES |
|
| Plug Type |
EU |
| Standards and Protocols |
HomePlug AV2, IEEE 1901, IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.11b/g/n (2.4 GHz), IEEE 802.11a/n/ac (5 GHz) |
| Interface |
3 Gigabit Ethernet Ports |
| Button |
Pair, LED On/Off, Wi-Fi, Reset |
| Power Consumption |
Maximum: 13.7W, Typical: 11W |
| LED Indicator |
Power, Powerline, Ethernet, Wi-Fi (2.4 GHz), Wi-Fi (5 GHz) |
| Dimensions (WxDxH) |
3.0 × 1.7 × 6.0 in. (75 × 42 × 152 mm) |
| Range |
Up to 300 meters/1000 feet over existing electrical wiring |
| Compatibility |
Compatible with all HomePlug AV & HomePlug AV2 standard powerline adapters* |
| Transmission Speeds |
Powerline: up to 1300 Mbps Ethernet: 10/100/1000 Mbps |
| SOFTWARE FEATURES |
|
| Security |
Wireless: WPA-PSK/WPA2-PSK, WEP Encryptions, Powerline: 128-bit AES Encryption |
| Management |
TP-Link tpPLC App, or download new tpPLC Utility on PCs: www.tp-link.com/support/download |
| Modulation Technology |
OFDM |
| OTHERS |
|
| Certification |
CE, RoHS |
| Package Contents |
AV1300 Gigabit Passthrough Powerline ac Wi-Fi Extender: 1× TL-WPA8631P 1× Ethernet Cables 1× Quick Installation Guide |
| System Requirements |
System Requirements: Windows 10/8.1/8/7/Vista/XP, Mac OS, Linux System Requirements for tpPLC Utility: Windows 10/8.1/8/7/Vista/XP and Mac OS X (10.7 or later) |
| Environment |
Operating Temperature: 0°C~40°C (32°F~104°F) Operating Humidity: 10%~90% non-condensing Storage Humidity: 5%~90% non-condensing |
