S/W |
|
MCU Name |
RoseP |
etc |
WorldWide |
T-CON Update |
Yes |
Core Component |
|
DDR SDRAM |
Samsung |
Nand Flash Memory |
Samsung |
OneNand Flash Memory |
N/A |
FlexOneNand Flash Memory |
N/A |
Serial Flash Memory |
WINBOND |
HDMI Switch |
N/A |
Display Device Vender |
SDC |
Operation Condition |
|
Temperature (?) |
0?~40? |
Humidity (%) |
10%~80%, Non-Condensing |
Storage Conditions Temperature (?) |
-20?~45? |
Storage Conditions Humidity (%) |
5%~95%,, Non-Condensing |
Power |
|
Type (Internal/External) |
External Adaptor |
Power Supply Spec. |
AC100-240V 50/60Hz |
Power Consumption(Max) (W) |
N/A |
Power Consumption(Typical) (W) |
N/A |
Power Consumption (DPMS) (W) |
N/A |
Power Consumption (Off Mode) (W) |
N/A |
Power Consumption (Yearly) (kWh/year) |
N/A |
Power Consumption(Rating) |
N/A |
AC Input Power Freq. (Hz) |
50/60Hz |
SMPS/IP Board/Adapter |
DongYang E&P |
Design |
|
Color (Front) |
SILVER |
Color (Rear) |
SILVER |
Color (Stand Base) |
Silver |
Stand Type |
HAS PIVOT |
Height Adjustable Range |
120.0 ±5.0 |
Tilt Range |
-2.0° (±2.0°) ~ 25.0° (±2.0°) |
Swivel Range |
-30° (±3.0°) ~ +30° (±3.0°) |
Pivot |
-92.0° (±2.0°) ~ +92.0° (±2.0°) |
Wall Mount |
100 x 100 |
Function Key Type (Touch/Tactile/Joystick/One-key) |
Joystick |
Lighting |
Yes |
Label Rating |
N/A |
Injection Mode |
Normal |
Front Resin |
N/A |
Stand Packing Type |
ONE PACKING |
Dimension (WxHxD) |
|
Set without Stand (mm) |
719.7 x 414.7 x 49.2 |
Set with Stand (mm) |
719.7 x 584.6 x 263.5 |
Package Dimension (mm) |
815 x 200 x 530 |
Stand Dim (WxD) |
|
Stand (Basic) |
296.1 x 263.5 |
Stand (Minimum) |
N/A |
Weight |
|
Set Weight without Stand (kg) |
5.3 |
Set Weight with Stand (kg) |
8.4 |
Package Weight (kg) |
10.9 |
Accessory |
|
D-Sub Cable |
N/A |
DVI Cable |
N/A |
HDMI Cable |
Yes |
HDMI to DVI Cable |
N/A |
Display Port Cable |
Yes |
USB A To B |
N/A |
USB Type-C Cable |
N/A |
USB Type-C to Type-A Gender Cable |
N/A |
Thunderbolt Cable |
N/A |
HDMI to Micro HDMI Cable |
N/A |
Mini-Displayport to Display Port Cable |
N/A |
Camera |
N/A |
External Adapter |
Normal |
Power Cable |
1.5 m |
Clean Cloth |
N/A |
Install CD |
N/A |
Manual Book |
N/A |
QSG |
Yes |
Warranty Card |
Yes |
Remote Controller |
Yes |
Remote Controller Model |
TM2360E |
Batteries (for Remote Control) |
N/A |
E-Manual |
Yes |
Pogo Gender |
N/A |
Zigbee / Thread Module |
N/A |
Certification |
|
Energystar |
N/A |
TCO Certified |
N/A |
EPEAT |
N/A |
TUV |
Yes |
GS |
N/A |
Low Blue Light |
Yes |
Flicker Free |
Yes |
Intelligent Eye Care |
N/A |
Eye comfort 1000R |
N/A |
Product Carbon Footprint |
N/A |
UL Glare free |
Yes |
Pantone Validated |
N/A |
VESA CMR |
N/A |
Eco |
|
Energy Efficiency Class |
N/A |
Recycled Plastic |
Yes |
Software Support |
|
Security Update Period (At least 5 years) |
N/A |
[SMART] Video / Audio |
|
Expert Calibration |
N/A |
Smart Calibration |
Basic |
AI Upscale |
Yes |
Dolby Decoder |
MS12 2ch |
Q-Symphony |
N/A |
360 Audio |
Yes |
Active Voice Amplifier Pro |
Yes |
Adaptive Sound |
Adaptive Sound Pro |
Multiroom Link |
Yes |
[SMART] Smart Service |
|
Smart Type |
Smart |
Operating System |
Tizen™ |
Bixby |
Yes |
Far-Field Voice Interaction |
Yes |
Built-in Voice Assistant |
Alexa (GB, DE, FR, IT, ES, AT, IE) |
TV Plus |
Yes (GB, FR, DE, IT, ES, CH, AT, NL, SE, NO, DK, FI, PT, IE, BE, LU) |
Web Browser |
Yes |
SmartThings Hub / Matter Hub / IoT-Sensor Funtionality |
Yes |
Samsung Health |
Yes (GB, IE Only) |
Universal Guide |
Yes (GB, FR, DE, IT, ES) |
Media Home |
Yes |
3rd party Service Certification / Agreement |
Yes |
[SMART] Smart Feature |
|
Multi Device Experience |
Mobile to Screen, Screen initiate mirroring, Sound Mirroring, Wireless On, Tap View |
TV Access |
Yes |
Multi View |
upto 2 videos |
External Source Support |
2 |
My Contents |
Yes |
Flex Move Screen |
N/A |
Workspace |
N/A |
Easy Setup |
Yes |
Chat Togethter |
N/A |
NFT |
Nifty Gateway |
ConnecTime |
N/A |
ScreenVitals |
N/A |
Buds Auto switch |
Yes |
Daily+ |
Yes |
Workout Tracker |
Yes |
Multi Control |
Yes |
Now+ |
Now+ |
Knox Vault |
N/A |
9:16 Screen Support |
Yes |
DPMS |
Yes |
Accessibility - Voice Guide |
Yes |
Accessibility - Low Vision Support |
Enlgarge, High Contrast, SeeColors, Color Inversion, Grayscale, Picture Off |
Accessibility - Hearing Impaired Support |
Multi-output Audio, Sign Language Zoom |
Accessibility - Motor Impaired Support |
Slow Button Repeat |
Caption (Subtitle) |
Yes |
ConnectShare™ |
Yes |
EPG |
Yes |
MBR Support |
Yes |
Localization |
|
AoT |
N/A |
Local IoT Support |
N/A |
