| HARDWARE FEATURES |
|
| Processor |
Qualcomm 560MHz CPU, MIPS 74Kc |
| Memory |
64MB DDR2 RAM,8MB Flash |
| Interface |
1 10/100Mbps Shielded Ethernet Port (LAN/POE)
1 Reset Button |
| Power Supply |
Passive Power over Ethernet via LAN (+4,5pins; -7,8pins)
Voltage range: 16-27VDC |
| Dimensions ( W x D x H ) |
350 x 255 x 207 mm (13.8 x 10.0 x 8.1 in.) |
| Antenna Gain |
23dBi |
| Antenna Beamwidth |
7°(Azimuth), 10°(Elevation) |
| Protection |
15KV ESD Protection
6KV Lightning Protection |
| Enclosure |
Material: Outdoor PC stabilized plastic
Weatherproof: IP65 water and dust proof design |
| WIRELESS FEATURES |
|
| Wireless Standards |
IEEE 802.11a/n |
| Proprietary Protocol |
TDMA Mode (with Pharos MAXtream enabled) |
| Wireless Speeds |
Up to 150Mbps (40MHz,Dynamic)
Up to 72.2Mbps (20MHz,Dynamic)
Up to 36.1Mbps (10MHz,Dynamic)
Up to 18.05Mbps (5MHz,Dynamic) |
| Frequency |
5.15~5.85GHz |
| Transmit Power |
Max. 23dBm (Adjustable power by 1dBm) |
| SOFTWARE FEATURES |
|
| IPv6 |
Yes |
| Network Configuration |
WAN: Static/Dynamic/PPPoE/L2TP/PPTP
LAN: Static/Dynamic/DHCP
Forwarding: ALG/UPnP/Virtual Server/Port Trigger
Security: SPI Firewall/ Ping Forbidden/DoS Protection
Access Control
Static Routing
Bandwidth Control
IP & MAC Binding |
| Wireless Configurations |
Pharos MAXtream TDMA Technology
Selectable Channel Width: 5/10/20/40MHz
Auto Channel Selection
Transmit Power Control
Dynamic Frequency Selection(DFS)
WDS Enable/Disable
Security: WPA/WPA2, WPA-PSK/WPA2-PSK (AES/TKIP) Encryption,
64/128/152-bit WEP Encryption
SSID Broadcast Enable/Disable
Multi-SSID with VLAN Tagging(AP Mode only)
Distance/ACK Timeout Setting
Wireless MAC Address Filter
Wireless Advanced:
Beacon Interval/RTS Threshold/Fragmentation Threshold/DTIM Interval/AP Isolation/Short GI/Wi-Fi Multimedia
Long Range PtP |
| Management |
Discovery and Remote Management via Pharos Control application
HTTP/HTTPS Web-based management
System log
SNMP Agent(v2c)
Ping Watch Dog
Dynamic DDNS
SSH Server |
| System Tools |
Indicators:Signal Strength/Noise/Transmit CCQ/CPU/Memory
Monitors: Throughput/Stations/Interfaces/ARP/Routes/WAN/DHCP
Spectrum Analyzer
Speed Test
Ping
Traceroute
Antenna Alignment |
| System-level Optimizations |
Optimized IGMP Snooping/Proxy for multicast applications |
| OTHERS |
|
| Certification |
CE, FCC, RoHS, IP65 |
| Package Contents |
Outdoor Wireless CPE
24V 0.25A Passive PoE Adapter
Pole Mounting Kits
AC Power Cord
Installation Guide |
| System Requirements |
Microsoft Windows 98SE, NT, 2000, XP, Vista™ or Windows 10, Windows 8, Windows 7, MAC OS, NetWare, UNIX or Linux.
Note: We recommend you to use one of following Web browsers for an improved user experience: Google Chrome, Safari, and Firefox. IE browsers are not recommended. |
| Environment |
Operating Temperature: -40°C~70°C (-40°F~158°F)
Storage Temperature: -40°C~70°C (-40°F~158°F)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~95% non-condensing
|
